Bar grating double gate Garden
Art.-No. 617448
- Height:
- 750 mm
- Width from middle to middle of post:
- 2988 mm
- Post length:
- 1250 mm
- Post dia.:
- 60 mm
- Frame thickness Ø:
- 42 mm
- Filler material:
- 50 x 250 mm
- Fastening type:
- ZEINB
- Opening:
- 90 °
- :
- 10 years
- Material/surface:
- raw steel, zinc phosphate plated, green powder-coated RAL 6005, for setting in concrete
- UNIT:
- 1
- PU:
- Piece
- Systems:
- Garden
- Surface / Colour:
- GRUEN
- Type:
- divided in the middle
- Weight per UQ (kg):
- 33.000 kg
Article-No.
Height
Width from middle to middle of post
Post length
Post dia.
Action
Article-No.617448
Height750 mm
Width from middle to middle of post2988 mm
Post length1250 mm
Post dia.60 mm
Article-No.617455
Height1000 mm
Width from middle to middle of post2988 mm
Post length1500 mm
Post dia.60 mm
Article-No.617462
Height1250 mm
Width from middle to middle of post2988 mm
Post length1750 mm
Post dia.60 mm
Article-No.617653
Height1500 mm
Width from middle to middle of post2988 mm
Post length2000 mm
Post dia.60 mm
- The specified height matches the frame dimension.
- Two hook posts included.
- With accessory kit consisting of galvanised tube frame lock (opening direction DIN left and right), profile cylinder with two keys, drop bolt, stop and hooks.
