Tee hinge
with press-fitted pin
Art.-No. 308872
raw steel, black cataphoretic coating
- Dimension a:
- 591 mm
- Dimension b:
- 45 mm
- Dimension c:
- 115 mm
- Dimension d:
- 30 mm
- Material thickness:
- 4 mm
- Quantity x hole Ø:
- 2 x Ø6.8 mm
- Quantity x hole (LxW):
- 6 x ( 7.5 x 7.5 ) mm
- Material/surface:
- raw steel, black cataphoretic coating
- Systems:
- Hinges and hangers,Wooden gate fittings,Band hooks and hooks
- Surface / Colour:
- black
- Belt length:
- 591 mm
- Weight per UQ (kg):
- 0.760 kg
- Content Unit:
- 10 Piece
Article-No.
Dimension a
Dimension b
Dimension c
Dimension d
Action
Article-No.
307004
Dimension a
291 mm
Dimension b
45 mm
Dimension c
115 mm
Dimension d
30 mm
Article-No.
307011
Dimension a
391 mm
Dimension b
45 mm
Dimension c
115 mm
Dimension d
30 mm
Article-No.
307028
Dimension a
491 mm
Dimension b
45 mm
Dimension c
115 mm
Dimension d
30 mm
Article-No.
308872
Dimension a
591 mm
Dimension b
45 mm
Dimension c
115 mm
Dimension d
30 mm
- Durable thanks to Galvanising, ideal for outdoor use thanks to high weather resistance.
